Specification:
Certification: CE
Origin: Mainland China
Type: Wireless
Max. LAN Data Rate: 300Mbps
Standards And Protocols: Wi-Fi 802.11g,Wi-Fi 802.11b,Wi-Fi 802.11n
Package: Yes
Color: White
Hardware: Chip MT7628DA+L716
Memory: 64MB
Flash memory: 8MB
Wireless standard: Support IEEE802.11b/g/n standard
Wireless speed: 2.4GHz: 300Mbps
Antenna gain: 3dBi antenna
Power parameter: DC12V, 1A power adapter
Maximum power consumption: Less than 12W
MTBF: >250000H
Installation method: Desktop
Protection grade: IP31
Indicator light: Power supply, 4G status, network interface, WiFi, signal
Operating environment:
Working temperature: - 10 ℃ - 55 ℃
Storage temperature: - 40 ℃ - 70 ℃
Operating humidity: 10%-90% RH, non condensing
Storage humidity: 5%-90% RH, non condensing
RF parameters:
Maximum transmitting power: 82mW (about 19dBm)
Maximum receiving sensitivity: - 93dBm
Operating frequency: 802.11b/g/n: 2.412GHz - 2.472GHz
Physical interface: 1 X 10/100Mbps WAN; 3 X 10/100Mbps LAN Ethernet ports; 1 X RESET button; 1 X DC power interface; 1 X common SIM card slot
Product size: 185x125x42mm/7.28x4.92x1.65in
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
Package Content:1 X Router
1 X Power Supply
1 X Instruction
