Specification:
Comprehensive index
Service environmental conditions:
600V CAT IV and 1000V CAT. Ill
Pollution level: 2
Altitude ＜ 2000m
Working environment temperature and humidity: 0 ~ 40 ℃ (< 80% RH, not considered at V10C).
Temperature and humidity of storage environment- 10-60 ℃ (< 70% RH, remove the battery).
Temperature coefficient: 0.1X accuracy / ℃ (< 18 ℃ or,28 ℃)
Maximum allowable voltage between measuring terminal and earth: 600V DC or 600V AC RMS
Fuse protection: Ma gear: fuse FF 200mA / 250vo
Conversion rate: about 3 times / s, analog bar 30 times / s.
Display: 4000 counts LCD display. The unit symbol is automatically displayed according to the functional gear
Overrange indication: the LCD will display \"OL\".
Input polarity indication: automatic display number.
Power supply: DC 3V
Battery type: AA battery (not included)
Product size: 200 * 37.2 * 30.2mm
Product material: ABS shell
Color: Black
Specification Range
DC voltage 400mV / 4V / 40V / 400V / 600V
AC voltage 4V / 40V / 400V / 600V
Resistance (Ω) 400 / 4K / 40K / 400k / 4m / 40m
Diode 4V
Buzzer on and off 400 (OMH)
DC current 40mA / 200mA
AC current 40mA / 200mA
Capacitance 4nF / 40nf / 400nf / 4uf / 40uf / 400uf / 4mf
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
Package Content:
1 x Voltage Multimeter
1 x Test Line
1 x Packing Box
1 x Manual
