Specification:
Origin: Mainland China
Model: USB (Without Bluetooth-compatible), Wireless (With Bluetooth-compatible) (optional)
Color: Black, White (optional)
Working frequency: 134.2Khz/125Khz
Support labels: EMID, FDX-B (ISO11784/85)
Reading and writing range: 2-12mm glass tube label ＞ 8cm; 30mm animal ear labels>20cm (related to label performance)
Standard: ISO11784/85
Reading time:<100ms
Signal indication: 0.91 \"high brightness OLED screen, buzzer
Power supply: 3.7V (lithium battery)
Storage capacity: 128 pieces of information
Communication interface: USB2.0, wireless 2.4G+Bluetooth
Language: English
Working temperature: -10 ℃~50 ℃
Storage temperature: -30 ℃~70 ℃
Size: About 168x88x15mm/6.61x3.46x0.59inch
Weight: 120g
Operating instructions:
Open the device and scan.
Press the scan button to open the device and open the scan model
If a label is detected, it will be displayed on the screen. If no label is detected, it will be displayed as\' No Label \'.
The device can be charged and uploaded data through a USB cable.
When the device is connected via USB, \"USB\" will be displayed in the upper left corner, and the battery status will be displayed in the charging state.
The device is connected via wireless 2.4G, and the label data will be uploaded to the receiving device in real-time. After inserting the receiver, the wireless connection symbol will be displayed in the upper right corner of the screen
Press and hold the scan button for 3 seconds, and the data will be uploaded from the scanner, with a maximum of 128 records.
When reading labels, the scanner can be connected through a USB cable to upload data in real-time.
The scanner will shut down after 120 seconds of inactivity.
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
Package Content:1 * Card reader
1 * Data cable
1 * Instructions
Or
1 * Card reader
1 * USB receiver
1 * Data cable
1 * Instructions
