Specification:
Certification: NONE
Origin: Mainland China
Socket Type: LGA 2011
Application: Desktop,Laptop
Chipset: Intel H81
Chipset Manufacturer: Intel
Form Factor: ATX
Maximum Ram Capacity: 128 GB
Package: Yes
Memory channel: Double
Quality Certification: NONE
Support Memory Type: DDR3
Number Of Memory Slots: 4
PCI - E standards: PCI - E 3.0
Number of PCIe x 16: 1
Number of PCIe x 1: 1
Number of PCI: 2
Storage Interface Type: SATA,M.2 (NVMe)
Number of M.2: 1
Onboard LAN: 1x RJ45
Support USB Type: USB 2.0,USB 3.0
Back I/O Ports: COM
Special Function: NONE
Usage Scenario: Household,Gaming,Office
Processor compatibility: Intel Pentium
RAID Supported: no
Product Size: 216.00x190.00x20.00mm/8.5x7.48x0.79inch
Processor: Intel LGA2011-3 series processor (E5-V3 and V4 CPU with DDR3 support required)
Southbridge: H81 Chipset Series
Memory:
Technology: Dual Channel DDR3 1866MHz
Maximum Memory: 128GB
Memory Slots: 4 x 240Pin DDR3 DIMM slots
Rear I/O:
Ethernet: 1 Realtek Gigabit LAN card
PS/2: 1 PS/2 keyboard and 1 PS/2 mouse
Audio: 1 audio interface (MIC-IN, LINE-OUT, LINE-IN)
USB ports: four USB 2.0 ports; two USB 3.0 ports
Internal connectors:
USB ports: 4 (1 FUSB can be adapted out of two USB2.0 ports)
SATA port: 3 SATA ports (1 SATA3.0, 2 SATA2.0)
ATXPWR interface: 1 standard 1 * 8pin power socket; 1 standard 1 * 24pin power socket
Audio: 1 x 2*5pin socket JLPC: 1 x 2*5pin socket
M.2 interface: 1 M.2 interface (support PCIE M.2/SATA M.2)
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
Package Content:1 x Motherboard
1 x SATA Cable
1 x Baffle
