Specification:
Origin: Mainland China
Socket Type: LGA 1150
Application: Desktop,Mining
Chipset: Intel H81
Chipset Manufacturer: Intel
Package: Yes
Onboard LAN: 1x RJ45
Special Function: NONE
Usage Scenario: Gaming,Mining,Audio Video
Processor compatibility: Intel Core i7
RAID Supported: no
CPU
:LGA1150 lntel 4th generation 5th generation series CPU
Chip: Intel PCH H81
Memory: 2*UDIMM DDR3 1066/1333/1600MHz
Dual-channel, support up to 16GB
Storage: 1*SATA3.0, 2*SATA2.0, 1*M.2 2280 NVMe SSD
port, 1*M.2 2280 NGFF SATA SSD port
USB: 6*USB2.0 ports, 2*USB3.0 ports
LAN: 1*RTL8111H, Gigabit LAN port
Audio: ALC897 7.1 channel chip
BIOS: AMI EFI BIOS
Rear I/O ports: 1*
HDMI-Compatible, 1*VGA, 4*USB2.0 ports, 1*RJ45 port.
1*Audio(Line-out/Line-in/MIC).
1*PS/2 KinDisk, 1*PS/2 Mouse
On-board interfaces: 1*4pin CPU FAN pin, 1*SYS FAN pin.
1*Front Audio pin, 1*F_USB3.0 pin.
1*F_USB2.0 pin, 1*RS232 C0M pin.
1*Front control panel pin, 1*Speaker pin.
1*24pin ATX power connector, 1*8pin 12V power connector
Expansion Slot: 1*PCIE3.0x16 slot, 1*PCIE2.0x1 slot
Product size: 215.00x170.00x20.00mm
Product Size: 8.46x6.69x0.79inch
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
Package Content:1 X Motherboard
