Specification:
Model: H927
Color: black
Material: ABS+metal
H927 (support: Asia, Africa, Southeast Asia)
4G LTE: B1/B3/B5/B8/B34/B38/B39/B40/B41
3G WCDMA: B1/B5/B8
2G GSM/EDEG: B3/B8
H927-EU (support: Europe, Middle East, Asia, Africa, Southeast Asia)
4G LTE: B1/B3/B5/B7/B8/B20/B28/B38/B40/B41
3G WCDMA: B1/B5/B8
GSM/EDEG: B3/B8
H927-USA (support: America, Australia, Europe, Middle East, Asia, Africa, Southeast Asia)
4G LTE: B1/B2/B3/B4/B5/B7/B8/B12/B17/B28/B66/B38/B40/B41
3G WCDMA: B1/B2/B4/B5/B8
4G LTE CAT4 150Mbps
External antenna port: 4G antenna (SMA) 1 (expansion 2)
External antenna port: WiFi antenna (SMA) 1 (expansion 2)
Support WiFi users: up to 16 users
WiFi transmission: 802.11b/g/n
LAN RJ45 1
Use SIM card
Product size: about 85 * 80 * 35mm/3.35 * 3.15 * 1.38inch
Single gross weight: 0.3kg
How to use the router:
1. Push down the rear cover.
2. Insert the SIM card with the card core facing down
3. Plug the USB port into the power supply to obtain WiFi
4. Connect to WiFi and get online.
5. Connect to WiFi and open 192.168.1.1 in the browser to enter the background. The background can modify the WiFi name and password to add APN.
Please read:
1. Before purchasing, you can check the frequency band in the following link to confirm whether it is suitable for local use
https://www.frequencycheck.com/countries
2. The following links can be queried for the frequency band used by the local country
https://www.gsmarena.com/network-bands.php3?sCountry=IRAN
3. Frequency band query link used by local national operators
http://en.wikipedia.org/wiki/List_of_LTE_networks
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
Package Content:1 x 4G Wireless Router
2 x Antenna
1 x Network cable
1 x Packaging
