Specification:
Origin: Mainland China
Advantages after upgrading:
1. Brand-new system: supports brightness adjustment (for outdoor use), bandwidth adjustment and other functions,
2. Brand-new hardware: supports independent headphone amplifier circuit, and the headphone listening volume is higher
3. High-quality production process: some manufacturers mixed inferior accessories in the old version, and we use all new parts for production
Parameters:
Master control: ESP-32-S3
Working mode: FM/AM/LSB/USB (note, does not support aviation band)
Receiving band: HF/SW/MW/VHF
Frequency range: LW, MW, SW (150kHz - 30MHz), VHF (64-108Mhz)
Screen: 1.9inch, 170*320 resolution
Charging port: TYPE-C (cannot use fast charging)
Audio interface: 3.5mm
Antenna interface: SMA-KE (inner hole)
Battery capacity: 800ma
Product size: about 80.00x35.00x20.00mm/3.15x1.38x0.79inch
Body material: plastic
Note:
Due to different monitor settings and lighting conditions, the actual color of the item may vary slightly from the pictures. Thanks for your understanding!
Please allow a 1-2 cm difference in measurements due to manual measuring.
Package Content:1 x Radio
1 x Antenna
1 x Earphones
1 x Instruction Manual
1 x USB Cable
