Specification:
Optional: concealed style, regular style (optional)
Image sensor:
1/4 "CMOS (0308) (concealed style)
1/605 "CMOS (0308) (regular style)
Effective pixels: 640 (H) x480 (V)
Minimum illumination: 0.5Lux/F2.0 color); 0.02Lux/F2.0 (black and white)
White balance: automatic tracking of white balance
Gain control: automatic
Signal to noise ratio: greater than 50dB
Backlight compensation: automatic
Wide dynamic: YES (concealed style), NO (regular style)
Electronic shutter: 1/4-1/10000s
Day and night mode: Filter color to black
Focal length: 2.4mm
Horizontal perspective: 100 degrees (concealed style), 55 degrees (regular style)
Aperture count: F2.0 (concealed style), F2.4 (regular style)
Infrared night vision lamp: 4 pieces, 3MM, flat head, angle 90850 infrared light (regular model)
Main chip: JR
Indoor unit material: ABS engineering plastic
Outdoor unit material: zinc alloy
LCD screen type: 2.4 inches
LCD screen resolution: 240 (RGB) * 320
TF card: supports up to 32G
Maximum image size: 640x480
Standby current: 100UA (concealed style), 80UA (regular style)
Working temperature and humidity: -30 ℃ -65 ℃ (outdoor)/-10 ℃ -50 ℃ (indoor) humidity less than 90%
Protection level: IP55
Installation method: screw hanging plate
Applicable door: 30-110mm
Suitable for cat eyes: 15-50mm
Product size: 80 * 80 * 18mm/3.14 * 3.14 * 0.70inch
Packaging size:
190 * 117 * 45mm/7.48 * 4.60 * 1.77inch (concealed style)
117 * 95 * 75mm/4.60 * 3.74 * 2.95inch (regular style)
Gross weight: 235g
The machine supports TF cards, with a maximum support of 32GB.
a) Without card insertion, it supports taking photos and can be used in hotels to better protect visitor privacy.
b) Insert a memory card, you can manually take photos, apply it to your home, and store and query records.
Automatic cycle coverage, intelligent recognition. After the TF card memory is full, new photos will automatically overwrite the oldest ones in chronological order, without the need for regular deletion. The latest photos or videos will be automatically saved.
The machine provides a recording mode:
a) Photography mode: When the machine is in monitoring mode, briefly press the menu button to take photos
There are two power supply methods for the machine:
a) 3 AAA dry batteries for power supply;
b) 5V1A-5V2A Micro USB, providing power to the machine.
The machine adopts an energy-saving and energy-saving design, and the indoor unit automatically shuts down the screen in 15 seconds to enter standby mode. It can be used for about 180 days and can be used for about 90 days (please refer to the energy-saving reminder card for details).
Note:
The machine can be powered by batteries and power sources. The factory does not come with a battery, and the battery needs to be prepared by oneself. The battery model is AAA battery.
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
Package Content:1 x Indoor host
1 x Outdoor host
8 x Screws
1 x Hanging board
1 x Instruction manual
