W1411 Digital Temperature Controller 12/220V High Precision Thermostat Control Electrical Appliances Heat/Cooling Switch Instrument
Feature:
1. When a simple temperature controller is used, set an opening temperature and a closing temperature. To achieve the set temperature on or off, so as to achieve the constant temperature effect. There are two temperature control modes: heating and cooling. The heating mode refers to that the heated product is opened below the start temperature and closed above the stop temperature. The cooling mode uses refrigeration cooling equipment, such as fan air conditioner, which is opened above the opening temperature and closed below the stop temperature. The setting range is: - 19-99 degrees, and the display accuracy is 1 degree
2. It is directly used as a timer and has the function of intermittent switch: it means that the equipment is opened for a period of time, closed for a period of time, then opened, and then closed for a straight cycle. Setting range: 1-99 minutes (function F1)
3. It is directly used as a timer. It has the function of countdown shutdown. It will shut down after running to the set time. The setting range is 1-9 hours and 59 minutes (function F24. It is directly used as a timer. The function of reserved startup means to set the time and start up when the time comes. The setting range is 1 minute to 99 hours and 59 minutes. (function F3) The timing function has nothing to do with temperature control. It does not need to set the opening and closing temperature directly, that is, it is controllable
Specification:
Product model: W1411
Temperature measurement range: 20 degrees
Temperature measurement accuracy: ± 0.3 ℃
Temperature control range: - 19-99℃
Control accuracy: 1℃
Temperature probe: NTC10 kK (standard 1m waterproof probe)
Power supply voltage: DC12v DC24 / 220V
Applicable environment: - 25-55 ℃
Humidity 20% - 80% (non condensing)
Output type: 10A relay output
Appearance size: 75 * 55 * 31mm/3X2.2X1.2in
Function: This product adopts a single-chip control system and high-precision temperature control probe, which is obviously superior to the humanized design of windows of similar products in temperature control performance, and the start value and stop value are displayed in real time. It has the functions of intermittent work, timing switch on and off, etc
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
Package Content:
1 X Temperature Controller
